Talk to Your Telemetry: Debugging LLMs with OpenLIT's Otter AI Copilot

Introduction

As LLM applications grow into multi-agent systems and multi-step RAG pipelines, the telemetry they produce grows with them. Developers end up wading through nested spans and tool calls just to answer simple questions: Why did this trace take 9 seconds? What did this session actually cost? Which model should we route this task to?

Answering those questions usually means hand-writing SQL against your telemetry store, or clicking through span-by-span until something looks wrong. OpenLIT's Otter is a chat-based copilot built directly into the dashboard to shortcut that process. It isn't a general-purpose chatbot bolted on top of your data—it's a tool-calling agent (built on the Vercel AI SDK) wired directly into OpenLIT's own platform services: ClickHouse, the Rule Engine, the Vault secret manager, and the Prompt Hub. Because OpenLIT is fully open-source and self-hosted, Otter runs inside your own infrastructure—your prompts, traces, and credentials never have to leave your VPC.

This post walks through what Otter can actually do today, grounded in the real tool implementations rather than the marketing pitch, plus a worked example of using it to investigate a slow, repetitive trace.

Why It's Important

Once you have OpenTelemetry-native traces flowing in—via a single openlit.init() call in Python or init() in the TypeScript SDK—you're sitting on a large amount of structured data: span hierarchies, token counts, costs, latencies, and any custom attributes you tag. The bottleneck shifts from collecting telemetry to interrogating it quickly enough to be useful during an incident or a routine cost review.

That's the gap Otter closes:

• No manual SQL required. Otter can write and execute ClickHouse queries against your otel_traces table on your behalf, filtered by attributes you already emit—session.id, user.id, tenant, or any custom tag.

• Direct write access to platform primitives. Otter doesn't just read data back to you—it can create Rule Engine rules, store secrets in the Vault, register custom model pricing, and manage Prompt Hub entries, all from a chat turn.

• Self-hosted by default. Because OpenLIT is OTel-native and self-hosted, Otter's reads and writes happen against your own ClickHouse instance and Postgres-backed platform services—useful if you're operating under HIPAA/GDPR-style constraints on where trace data (which can include user conversations) is allowed to live.

How to Implement/Do It

1. Get traces into OpenLIT

Otter analyzes whatever OpenLIT's automatic instrumentation already captures. There's no separate setup for Otter itself beyond having traces flowing in:

import openlit

openlit.init(
    otlp_endpoint="http://127.0.0.1:4318",
    application_name="agent-orchestrator",
    environment="production",
)

import * as openlit from 'openlit'

openlit.init({
  otlpEndpoint: 'http://127.0.0.1:4318',
  applicationName: 'agent-orchestrator',
  environment: 'production',
})

Any custom attribute you set on a span (a session.id, a tenant tag, or a bespoke field like tool.call.count) becomes something you can later ask Otter to query or build a rule against.

2. Ask Otter to analyze a trace

Two tools cover single-trace and batch analysis:

• analyze_trace takes a span_id and a scope (trace or span) and returns a structured review—covering things like whether the routing/execution path picked the right tools, avoided repetitive calls, and kept orchestration efficient, plus a look at token/cost efficiency.

• analyze_trace_batch does the same across up to five spans at once, useful for comparing a handful of slow runs.

This is a real, working feature, but it's worth being precise about what it is: an LLM-generated qualitative read of the trace, not a deterministic loop detector or anomaly-detection system. It's a strong first pass, not a guarantee it catches everything.

3. Query traces by attribute, conversationally

analyze_traces_by_attribute is where Otter's ClickHouse integration is most direct—you give it a key/value pair, and it builds and runs a query along the lines of:

SELECT TraceId AS traceId, any(SpanId) AS spanId, count() AS spanCount, max(Timestamp) AS lastSeen
FROM otel_traces
WHERE SpanAttributes['session.id'] = 'session_abc123'
GROUP BY TraceId
ORDER BY lastSeen DESC
LIMIT 20

You can ask for this in plain language ("find the latest trace for session session_abc123"), and Otter resolves the attribute key/value, runs the query, and hands you back the matching traces to analyze further.

4. Turn a finding into a Rule Engine rule

Once you've spotted a pattern worth flagging automatically, create_rule lets Otter build a rule out of condition groups—each with a field, an operator (equals, contains, gt, gte, and similar), and a value. link_entity_to_rule then attaches that rule to a context document, prompt, or evaluation.

It's important to be clear about what "field" means here: the Rule Engine is generic. It matches on whatever data you're already capturing—there's no built-in concept of "tool call count" or "loop detected." If you want a rule like tool.call.count > 10, you need to be emitting that attribute yourself; Otter just makes the rule-authoring conversational instead of a form.

5. Register custom model pricing

If you're running local models via Ollama or vLLM alongside cloud APIs, create_custom_model lets you register a provider, model ID, and input/output pricing in USD per million tokens. Once registered, that model's costs are computed correctly and show up consistently across dashboards and Otter's own cost analysis.

6. Manage secrets and prompts

create_vault_secret stores a credential in OpenLIT's Vault, automatically normalizing whatever key you give it to UPPER_SNAKE_CASE (so anthropic key or anthropic-key both become ANTHROPIC_KEY). On the Prompt Hub side, create_prompt (plus get_prompt, update_prompt_version, list_prompts, and delete_prompt) lets Otter manage versioned prompts with {{variable}} templating directly from chat.

A Worked Example

Here's what a real interaction looks like, using the tools above:

Step 1 — Trace diagnostics

You: "Otter, find the latest trace for session session_abc123 and analyze it."

Otter: Runs analyze_traces_by_attribute matching session.id, then analyze_trace on the result: "I found trace t-ef8a2 with 18 spans. As part of the routing/execution-path review, I noticed the agent called get_inventory_status 12 times, each time receiving 404 Not Found—likely the cause of the repeated calls. Total latency was 9.4 seconds, costing $0.12."

Step 2 — Configure a rule

You: "We tag a tool.call.count attribute on our agent spans—create a rule to flag anything over 10."

Otter: Runs create_rule with a condition matching tool.call.count > 10: "I've created Rule agent_loop_limit (ID rule-bf92a). You can now filter or analyze runs that match it in the dashboard."

Step 3 — Register a secret and custom pricing

You: "Store our Anthropic key as anthropic key in the vault, and set pricing for our local gemma3 model on Ollama: $0.15 input and $0.45 output per million tokens."

Otter: Normalizes the key to ANTHROPIC_KEY, calls create_vault_secret, then create_custom_model for provider ollama: "Stored ANTHROPIC_KEY in the Vault, and registered gemma3 under ollama with $0.15/M input and $0.45/M output pricing."

Benefits and Outcomes

• Faster first-pass triage. Going from "something's slow in session X" to a candidate root cause takes one or two chat turns instead of a manual ClickHouse query and a span-by-span read.

• Lower barrier to writing Rule Engine rules. Condition groups are powerful but fiddly to build by hand in a UI form; describing the rule in plain language and letting Otter fill in the fields removes friction.

• Accurate cost accounting for hybrid deployments. Registering local-model pricing once means every dashboard view and every future Otter cost analysis reflects real blended spend, not just cloud API costs.

• Data stays where it already lives. Because Otter runs against your self-hosted ClickHouse and platform database, none of this requires exporting trace data to a third-party SaaS to get conversational analysis.

When It's Required/Recommended

Otter is most useful once you already have a meaningful volume of traces flowing through OpenLIT and you're spending real time on manual investigation—teams running multi-agent pipelines (LangGraph, CrewAI, or custom orchestrators) where tool-calling loops are a recurring failure mode, or teams mixing local and cloud models who need pricing to reflect reality. It's less necessary if you're still early with a single-service integration and low trace volume—at that stage, browsing traces directly in the dashboard is usually just as fast.

Keep in mind Otter's actual capabilities when deciding how much to lean on it: it's a strong assistant for querying, summarizing, and rule-authoring, not an automated anomaly-detection or cost-optimization system that runs in the background without being asked.

Conclusion

Otter turns a handful of real platform primitives—ClickHouse queries, Rule Engine conditions, Vault secrets, custom model pricing, and Prompt Hub entries—into something you can drive conversationally instead of through separate forms and hand-written SQL. It's a practical accelerant for trace triage and rule authoring, built on top of OpenTelemetry data you're already collecting.

• 🚀 Run OpenLIT locally:

  git clone https://github.com/openlit/openlit.git
  cd openlit
  docker compose up -d

• ⭐ Star the repository: github.com/openlit/openlit

• 📖 Explore the docs: docs.openlit.io

What's the first trace you'd ask Otter to investigate?
